Printing Factory Equipment Binding Machines Book Binder Machine

FOB Reference Price:Get Latest Price
US $1-10,000 / Set | 1 Set/Sets (Min. Order)
Supply Ability:
5 Set/Sets per Month
Port:
Shenzhen
Report Suspicious Activity
Overview
Quick Details
Type:
Wire Binding Machine
Power:
Electricity
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HONGYUAN
Model Number:
DWC-520A
machine:
book binder machine
feeding mode:
manual
double wire:
1/4"-7/8"
max.paper width:
520mm
max.binding width:
507mm
min,paper length:
30mm
working speed:
1000-1500 cycles/hr
power:
220V/1ph/50-60Hz
air pressure:
6-8 bar
net weight:
300kg
Packaging & Delivery
Packaging Details
in wooden box
Delivery Time
10-15 working days

Automatic double wire binding machine is for binding calender,notebook, magzine ect.





Working speed up to 1200-1700 books per hours.

Bining diameters can be 1-4" to 7/8"

Skip-bindings at one time are available, up to 5 skip binding per once

Touch screen and automatic error reminder

Automatic hanger binding device, automatic books convey device





MODEL



DWC-520A

Feeding Model



Manual

Handing of Double Wire



Automatic cutting,insertion&closing&conveying

Wire Specifications



Diameter1/4"-7/8"          Pitch:3:1,2:1

Max.Paper Width (mm)



520

Max.Binding Width (mm)



507

Min.Paper length (mm)



75

Working Speed (cycles/hy )



1200-1700

Power Supply



220V/1ph/50Hz

Air Compressor(not included) (kw)



1.5

Air Pressure (bar)



6-8

Machine Dimensions (mm)



1000(L)x760(W)x1230(H)

Outside Wooden Box Dimensions (mm)



1480(L)x1050(W)x1570(H)

Net Weight (kg)



271

Gross Weight (kg)



350

Dimensions of Pay-off Unit (mm)



490(L)x760x1230

Neet Weight of Pay-off Unit



65





Binding moulds:

B)3:1 pitch, 1/4' coil diameter

C)3:1 pitch, 5/16' coil diameter

D)3:1 pitch, 3/8' coil diameter

E)3:1 pitch, 7/16' coil diameter

F)3:1 pitch, 1/2' coil diameter

G)3:1 pitch, 9/16' coil diameter

H)2:1 pitch, 5/8' coil diameter

I )2:1 pitch, 3/4' coil diameter

J)2:1 pitch, 7/8' coil diameter



Our company are specialized in manufacturing high quality book binding machines, such as nylon-coated double loop wire,plastic spiral, calendar hager, plastic combs ect., and related binding machines. We have passed ISO9001 international quality system; All of our binding materials are passed strict SGS testing and meet the standard of European environmental requirements. Most of our machines have CE.



We have full sets of advanced automatic production equipments and an experienced production management team. Since 2003, we have developed a professional and integrated system for talking your order from sample to productionk, keeping you well informed at every stage of the process. Competive prices, strict qualtiy-control, professional service and prompt delvery are our main principle to work with you. Warmly welcome your contact and visit !
